Description
Conveyor Weight Checker also named Check weigher, check weighers, check weigher machine, weight sorting machine, weight sort machine, online check weigher, online weight sorting machine, weight checker, weight pick, conveyor check weigher.
checkweigher machine are also known as Check weigher ,dynamic scales and conveyor check weigher, it is used to ensure that the weight of a pack of the commodity is within specified limits, and suitable for testing, counting and sorting 1~80kg packaged products (boxes, barrels, bags) or processing parts, it is simple and clear to operate.
Whether you need to check the current actual weight or perform a completeness check, or a sort, or a classification. The base frame of checkweight is made of solid SUS304 stainless steel material,which enables high precision weight determination at average to high conveyor speeds or throughput rates and provides 100% product checks in accordance with national prepackage regulations.
A Checkweigher system will check weights of products whilst in motion, rejecting any products that are over or under the set weight.
What’s more, a checkweigher can effectively improve your overall equipment efficiency,so this checkweight machine system would reduce your production cost.
Key Feature
*Basic Weighing Function : Affordable automatic checkweighers typically focus on accurate weighing capabilities to ensure products meet predefined weight criteria.
* Simple User Interface: These checkweighers often have straightforward interfaces for ease of use, with minimal training required for operators.
* Compact Design: Compact design automatic checkweigher make it is possible to work in small production spaces.
* Cost-Effective Maintenance: Our high quality check weight system are all made of SUS304 stainless steel matieral and the latest technology. So this checkweight nearly don’t need any maintaince .
* Customizable Options: Our checkweighers may offer optional features or customizations to tailor the system to specific production needs without adding unnecessary complexity.
Technical Parameters
| Weighing range | 200g | 1000g | 3000g | 15kgs | 40kgs | 50kgs |
| Weighing accuracy | ±0.05g-±0.1g | ±0.3g-±1g | ±0.5g-±2g | ±2g-±10g | ±5g-±15g | ±8g-±20g |
| Display resolution | 0.01g | 0.1g | 0.1g | 1g | 1g | 5g |
| Conveyor speed | 20-60m/min | 30-100m/min | 30-90m/min | 30-70m/min | 20-35m/min | 15-25m/min |
| Sorting speed | 180pieces/min | 160pieces/min | 80pieces/min | 70pieces/min | 30pieces/min | 30pieces/min |
| Belt height | 700mm±30mm | 700mm±30mm | 700mm±30mm | 700mm±30mm | 700mm±30mm | 700mm±30mm |
| Infeed part | 250(L)*120(W)mm | 400(L)*210(W)mm | 450(L)*300(W)mm | 620(L)*400(W)mm | – | – |
| Weighing part | 250(L)*120(W)mm | 400(L)*210(W)mm | 450(L)*300(W)mm | 620(L)*400(W)mm | 900(L)*500(W)mm | 1200(L)*600(W)mm |
| Rejection part | 400(L)*120(W)mm | 700(L)*210(W)mm | 900(L)*300(W)mm | 900(L)*400(W)mm | 900(L)*500(W)mm | 935(L)*600(W)mm |
Why You Need A Check Weigher?
A Checkweigher equipment is becoming a key element of production operations, because it is not just used for weighing, but also it can actually optimise your whole production process.The benefits of a checkweigher include:
* Avoiding costly fines with 100% weight inspection
* Saving materials, so that produce more products and profits
* Prompting production processes and equipment efficiency
* Saving labor and personnel costs
* Reducing false rejects and rework
* Maintaining the featrues of your brand
Benefits of CheckWeights
Our CheckWeigher machine comes with a large screen to help you better analyze weights and store large amounts of data. This makes your packaging line more efficient and accurate while increasing productivity.
* Quicker & Easier Cleaning
* More Productive Operation
* Higher Reliability of Equipment
* Better Food Standards
* Reduce the risk of accidents and injuries.
* Better operational efficiency.
* Versatile and ideal for many different conveyor systems.
* Easy to integrate into existing systems.
* Cost-effective improvements to workflow.
* Custom design and made standardized software configuration settings
* Detailed Analysis through our own software system are provided (including batch summary reports, daily batch reports, fail analysis reports, etc.)
Application of Check Weight Machine
* Food, Health & Pharmaceutical, Manufacturing
* Meat, Poultry & FishMeat, Poultry & Fish
* Fruit, Vegetables & NutsFruit, Vegetables & Nuts
* Convenience Food | Food-to-GoConvenience Food | Food-to-Go
* Dairy and Egg ProductsDairy and Egg Products
* Food including: meat, dairy, wet and dry ingredients, baked goods, confectionary products, Wet (dairy, hummus) Dry (rice, oatmeal), and Raw (chicken, beef, fish, vegetables and fruits).
* Non-food packages can be weighed including:
Transport;
*Pharmaceuticals:drugs,medicine；
* Automotive
* Chemicals; Rigid (cans, cardboard packages, plastic, glass) Soft (plastic, paper, foil), bullets;
* Metal manufacture and fabrication industries: bags of construction materials like cement;
