Description
The automatic checkweighers are also known also as belt weighers, the check weigher is used to check whether the weight of single product meet the needs of set goal , and the sorting device automatically eliminates the substandard products.
The maximum conveying speed of the sorting scale can be adjustable,ranging from 4 meter to 55 meters per minute. Its height can also be adjust if need.
This checkweight machine is equipped with a high-speed conveyor system, allowing for a continuous flow of products to be checked and weighed at a rapid rate. The Check Weight Conveyor is an essential component of the Automatic Check Weigher, which provide a stable and smooth platform for products to be weighed.
The check weight conveyor is mainly used for automatic weight detection, upper and lower limit discrimination or weight classification on various automatic assembly lines and logistics delivery systems.
It could embed in a variety of production/transportation lines and conveyor systems, weigh each product one by one and reject the wrong weight automatically.
The purpose of check weighing conveyor system from Simptek is used to do check weighing of the packaged commodities and accordingly reject the under weight and over weight boxes or bags as per the tolerance given in the settings
This check weight machine is widely used for online detection in rubber , silcone, food, toy, hardware, chemical ,bulk paper bags, plastic bags, cartons, metallized film packaging, electronics, pharmacy, food, beverage, health products, cosmetics, light industrial and agricultural products, etc. It is Not only used to check if a single finished product is within the preset target weight but also to check missing parts of a full carton (missing bottles, boxes, pieces, bags, cans, etc.) and other industries.
In addition, it can also directly replace manual weighing, in order to improve production efficiency and the consistency of weighing for manufactories .
Features of Simptek's Check Weigher Conveyor
Our Check Weigher Systems are designed with the following advanced features:
* High Accuracy: Equipped with sensitive load cells, our checkweight system ensures precision in weighing even the smallest variations in product weight.
* Automated Rejection System: The checkweight conveyor system automatically removes products that do not satisfied redefined weight range, and just keep the eligible item moving forward .
* Customizable Settings: Our check weighers can be tailored to suit various product sizes and weights, which allow this equipment suitable for various industries .
* User-Friendly Interface: With very simple and convenient controls, operators can easily set weight limits, monitor performance, and adjust settings.
* Durable Construction: Constructed with quality SUS304 stainless steel material, which ensure the checkweight feature long-lasting performance.
Standard Feature
*3g to 1,000g weight capacity
*+/- 0.3g accuracy
*up to 150 weighments/min.
*up to 65 FPM adjustable speed belt
*8.6” belt width
*9.8’ to 17.7’ belt length
Technical Parameters
| Weighing accuracy | about 30-50g |
| Weighing belt size | 900mm*600mm (L*W) |
| Weighing direction | From left to right (Facing the operation display) |
| Weighing sensor | Germany HBM |
| Control system | Dahang (Independent R & D) |
| Operation display | 8 inches touch screen |
| Weighing data output | USB port |
| Rejecting type | pusher with light alarming |
| Products parameters | Can restore and recall 100 products |
| Belt conveyor | PVC Belt |
| Language | English |
| Height of conveyor | 750+60mm (Customized) |
| Power supply | Single phase AC220V卤10%, 50/60HZ |
| Construction | SUS304, polishing |
| Using environment | Normal |
| Package | With plastic film inside and professional export wooden case outside. |
| HS code | 84232010 |
Why You Need A Check Weigher?
* Compact Design: Compact design automatic checkweigher make it is possible to work in small production spaces.
* Cost-Effective Maintenance: Our high quality check weight system are all made of SUS304 stainless steel matieral and the latest technology. So this checkweight nearly don’t need any maintaince .
* Customizable Options: Our checkweighers may offer optional features or customizations to tailor the system to specific production needs without adding unnecessary complexity.
Benefits of In-Line CheckWeigher
Our CheckWeigher machine comes with a large screen to help you better analyze weights and store large amounts of data. This makes your packaging line more efficient and accurate while increasing productivity.
* Reduce the risk of accidents and injuries.
* Better operational efficiency.
* Versatile and ideal for many different conveyor systems.
* Easy to integrate into existing systems.
* Cost-effective improvements to workflow.
* Custom design and made standardized software configuration settings
*Detailed Analysis through our own software system are provided (including batch summary reports, daily batch reports, fail analysis reports, etc.)
Application of Check Weight Machine
* Food, Health & Pharmaceutical, Manufacturing
* Meat, Poultry & FishMeat, Poultry & Fish
* Fruit, Vegetables & NutsFruit, Vegetables & Nuts
* Convenience Food | Food-to-GoConvenience Food | Food-to-Go
* Dairy and Egg ProductsDairy and Egg Products
